K1 is a 110 V AC contactor on a saw, its coil is switched by a solid-state relay, the SSR is driven from output pair 0 of a 1791ES-IB8XOBV4, and every 600 ms the contactor makes a small tick you can hear from the door of the panel. The scope on O0+ shows why: the … Read more
A 1734-AENT on a remote I/O rack stores its chassis size in non-volatile memory, and the user manual says in as many words that the chassis size setting is not communicated to the adapter during a connection request from the controller. Download a project with the new rack in it and the adapter you just … Read more
A Pt100 RTD input wired two-wire over 22 m of 0.5 mm² cable into channel 0 of a 1756-IR6I reads 104.1 °C in a bath that the reference thermometer says is 100.0 °C, and the same sensor with its third lead landed on RTN-0/C reads 100.0 °C. Lift lead A off the module and the … Read more
When a standard interlock is not enough, how to wire and configure a dual-channel E-stop on GuardLogix safety I/O, and the reset rule nobody may break.
