Safe Torque Off on a PowerFlex 755: How the 20-750-S Is Wired and What It Does Not Do

by
The safe torque off path through a PowerFlex 755: 24 V on SP and SE from the two contacts of a safety relay, the option module between them and the gate control driver, the driver feeding the IGBT bridge, and the AC line, DC bus and motor terminals marked as still live

A 20-750-S seated in port 4 of a PowerFlex 755, SP and SE landed on separate contacts of a 440R-D22R2, twenty-four volts measured on both pairs, and the drive faults the moment the contactor closes. The SAFETY enable jumper is still on the main control board, where it ships from the factory, and the manual … Read more

Wiring a Safety Input to PL d: the Device, the Two Channels and What the Relay Expects

by
Three subsystems of a guard stop function drawn left to right: the interlock device feeding two channels into a 440R-D22R2 relay and the relay driving two contactors with mirror contacts back into the reset loop, with the quantity each subsystem contributes named underneath

Four guard doors on a packing cell, a Trojan T15 tongue switch on each, 440K-T11390, all four pairs of contacts daisy-chained into one 440R-D22R2 relay, and the calculation for that stop function will not go past PL c. Every switch in the chain has its two direct-opening N.C. contacts, the wiring matches the drawing, and … Read more
